Welding of Hollow Structural Sections

by Jeffrey A. Packer
Bahen/Tanenbaum Professor of Civil Engineering, University of Toronto, Ontario, Canada
Matthew R. McFadden
Research Assistant, Department of Civil Engineering, University of Toronto, Ontario, Canada

March/April 2012

The welding of Hollow Structural Sections (HSS) does have some unique features. Unlike open sections, where welding is typically possible from both sides of an element, welding of HSS is only possible from one  side,  thus  requiring  larger  weld  sizes.  Second,  the  main  HSS  member  face  to  which  a  branch  is  welded is generally much more flexible than its wide‐flange counterpart, as the two webs of the main member  (which  act  as  stiffeners)  are  at  the  outside  of  the  connection  rather  than  in  the  middle,  as  would be the case with a W‐shape web. This increased flexibility of the connecting face tends to cause an uneven load distribution in the welded joint.

An important first step is to have selected the members in an HSS connection astutely. For truss‐type connections, the branch width‐to‐chord width ratio (β) should be relatively high (say 0.7 to 0.8), but still preferably enable the branch to sit on the “flat” of the main member if it is a square/rectangular HSS. (An exception to this recommendation are connections in Vierendeel frames, where matched‐width HSS [β  ≈  1.0]  are  typically  necessary  in  order  to  achieve  full  moment  capacity).   In  addition,  the  branch  thickness‐to‐chord thickness ratio (τ) should be relatively low; less than unity, with a value of 0.5 being a good target. These conditions will generate a truss‐type connection with a high static strength (and a high fatigue resistance too). As member selection is intimately tied to connection capacity, and most HSS connections are required to be unreinforced, it is clear that checking the connection capacity is the responsibility of the structural engineer.

Three basic types of welds account for practically all structural weld joints, including those between HSS: complete‐joint‐penetration  (CJP)  groove  welds,  partial‐joint‐penetration  (PJP)  groove  welds,  and  fillet  welds.

Complete‐Joint‐Penetration  groove  welds  (from  one  side  and  without  backing)  are  extremely  expensive, require specially qualified welders, and should almost never be specified for HSS connections. One exception that comes to mind is for a round HSS welded to a proprietary steel special‐purpose casting – the High‐Strength Connector by Cast Connex Corp., used with diagonal HSS braces in seismic  load‐resisting  braced  frames  (shown  in  Fig.  1).   In  this  case  the  tapered  nose  of  the  casting  inserted into the HSS or pipe essentially serves as backing.

Screen Shot 2020 05 28 at 7.39.40 AM Welding of Hollow Structural Sections
Figure 1: Illustrated [Image left] (a) and macro‐etched [Image right] (b) CJP joint between round HSS and Cast Connex High‐Strength Connector
Screen Shot 2020 05 28 at 7.40.10 AM Welding of Hollow Structural Sections
Figure 2: Macro‐etched PJP groove weld in a matched‐width (β=1.0) HSS connection

Partial‐Joint‐Penetration groove welds are an option for HSS connections, especially if fillet weld sizes become large (leg sizes over about ½ in.) and the branch member is reasonably thick. Prequalified joint details for PJP welds to HSS, particularly for the longitudinal welds in “matched box” connections as in Fig. 2, are given in AWS D1.1 (2010).

Fillet welds, being the least expensive and easiest weld type, are the preferred and most common weld type for HSS connections. The design of fillet welds in structural steel buildings in the US is governed by AISC 360‐10 Table J2.5 and is based on the limit state of shear failure of the weld using a matching (or under‐matching) filler metal. For a simple 90° T‐joint the LRFD resistance of a single weld is given by:

ФRn= ФFnwAwe = (0.75)(0.60FEXX)(D/√2)(weld length), where D = weld leg size.

The design of fillet welds in Canada is governed by CSA S16‐09 Clause, and although different coefficients are used, an identical resistance is obtained. Both AISC and CSA allow an enhancement to the nominal strength of the weld metal (of 1.0 + 0.50 sin1.5θ) for welds loaded at an angle of θ degrees to  the  weld  longitudinal  axis,  plus  include  some  further  provisions  for  weld  groups.   AISC  360‐10,  however, limits the sinθ enhancement factor to only weld groups where all elements are in a line or are parallel (also referred to as linear weld groups). Thus, the apparent inapplicability of this factor to HSS T‐,  Y‐  and  K‐connections  is  pointed  out  in  AISC  Design  Guide  No.  24  (Packer  et  al.,  2010).   The  CSA  standard, on the other hand, does not rule out the applicability of the sinθ factor for HSS connections, leading to a much greater resistance for a fillet weld group in a HSS connection and hence much smaller weld sizes (see Table 1). The prior edition, CAN/CSA S16‐01, included a check for shearing of the base metal at the edge of a fillet weld along the fusion face (see Fig. 3), which frequently governed and thus resulted in generally larger weld sizes at that time.

Screen Shot 2020 05 28 at 7.49.45 AM Welding of Hollow Structural Sections
Figure 3: 90° HSS T‐connection under branch axial tension [Image left] (a) and detail of the fillet weld showing assumed failure planes [Image right] (b)

Weld  Design for HSS‐to‐HSS connections  can  be  performed  to  either  of  the  following  two  design  philosophies (Packer et al., 2010; Packer and Sun, 2011):

  1. The weld may be proportioned so that it develops the yield strength of the connected branch wall at all locations around the branch, or
  2. The weld may be proportioned to resist the applied branch forces, with adjustments for uneven stress distributions along the length of the weld.

Examining Method No. 1, this will represent an upper limit on the weld size – and hence a conservative design  procedure.  For  example,  consider  the  simple  90°  HSS‐to‐HSS  T‐connection  under  branch  axial  tension load in Fig. 3, with sections manufactured to ASTM A500 Grade C and fillet welded with E70 electrodes. In this case all welds are oriented transversely (at 90°) to the applied load, form a non‐linear weld group, and one can consider that the HSS branch wall yield resistance, per unit length, is given by:

(Ф = 0.9)Fytb = 45tb kips/in, where tb is the branch wall thickness.

It is interesting to consider the fillet  weld effective throat size  that is required to develop this branch  wall resistance, according to various specifications/codes (see Table 1). Clearly there is quite a disparity.

Specification or CodeWeld Effective Throat
ANSI/AISC 360‐10 Table J2.51.43tb
AWS D1.1/D1.1M: 2010 Clause and Fig. 3.21.07tb
CSA S16‐09 Clause
CAN/CSA S16‐01 Clause
CEN (2005) or IIW (2009)1.10tb
Table 1: Comparison of fillet weld effective throats to develop the yield resistance of the connected branch member wall

Method  No. 2,  essentially  a  “fit  for  purpose”  approach,  involves  taking  weld  effective  lengths  into  account because HSS welded joints typically have highly varying load distributions around their perimeter.  For  joints  with  relatively  low  branch  forces,  the  use  of  weld  effective  lengths  may  lead  to  smaller weld sizes and result in a more economical weld design. The same effective weld size should still be maintained all around the attached branch, with the entire branch perimeter welded. (An exception to the latter may apply to the “hidden weld” in HSS‐to‐HSS overlapped connections). Some HSS weld effective lengths were introduced into AWS D1.1 in the 1990s, based on prior experimental research, then AISC 360 adopted these in 2005 and further expanded the coverage in Section K4 of AISC 360‐10. IIW (2009) specifically acknowledges the effective length concept for weld design but, like all other steel design specifications/codes except AISC 360 and AWS D1.1, does not prescribe any effective lengths.

To validate or further improve the HSS weld effective rules added to Section K4 of AISC 360‐10, an AISC‐sponsored experimental research project is currently being performed by the authors on weld‐critical HSS‐to‐HSS T‐connections, under branch in‐plane bending, and on weld‐critical HSS‐to‐HSS overlapped K‐connections within complete trusses. The heightened interest in welding of HSS is also reflected in the recent  formation  of  an  AWS  Tubular  Task  Group,  at  the  instigation  of  AASHTO,  primarily  to  address  tubular bridge construction.

AISC. 2010. “Specification for Structural Steel Buildings”, ANSI/AISC 360‐10, American Institute of Steel Construction, Chicago, IL.

AWS. 2010. “Structural Welding Code – Steel”, AWS D1.1/D1.1M:2010, 22nd. edition, American Welding Society, Miami, FL.

CEN. 2005.   “Eurocode 3: Design of  Steel Structures – Part1‐8:  Design of Joints”, EN1993‐1‐8:2005(E),  European Committee for Standardization, Brussels, Belgium.

CSA. 2001. “Limit States Design of Steel Structures”, CAN/CSA S16‐01, Canadian Standards Association, Toronto, ON.

CSA. 2009. “Design of Steel Structures”, CSA S16‐09, Canadian Standards Association, Toronto, ON.

IIW. 2009. “Static Design Procedure for Welded Hollow Section Joints – Recommendations”, 3rd. edition, IIW Doc. XV‐1329‐09, International Institute of Welding, Paris, France.

Packer, J., Sherman, D. and Lecce, M. 2010. “Hollow Structural Section Connections”, Steel Design Guide No. 24, American Institute of Steel Construction, Chicago, IL.

Packer,  J.A.  and  Sun,  M.  2011.   “Fillet  Weld  Design  for  Rectangular  HSS  Connections”,  Engineering  Journal, American Institute of Steel Construction, 1st. quarter, pp. 31 – 48.
